From Cell to Pack: Your Complete OEM Battery Solution
We are more than a cell supplier; we are your expert partner in custom battery pack assembly. Using our high-quality cylindrical cells, we provide full OEM services—from design and BMS integration to professional spot welding, casing, and testing. We help you bring a safe, reliable, and market-ready battery pack to your brand.
Key Features:
Full In-House Capability:
Cell supply, BMS design, welding, assembly, and testing under one roof.
Professional Spot Welding:
Ensures low resistance and highly reliable connections between cells.
Custom BMS Integration:
Tailored protection and smart features for your specific application.
Flexible Packaging:
Custom shapes, sizes, and connectors to fit your product perfectly.
Quality Assurance:
Every pack undergoes rigorous testing before shipment.
Dimensions:
Major Technical Parameters:
| HCITR26/70-36P | |||
| Item | Standard | Note | |
| Standard Capacity | 3600mAh | 1C (current value of 3600mA at 1C) | |
| Minimum Capacity | 3600mAh | ||
| Standard Voltage | 3.2V | ||
| Alternating Internal Resistance | ≤20mΩ | ||
| Charge Conditions | 3.65±0.05V 0.01C | 3.65±0.05V 0.02C | Constant-current charge to 3.65V at 1C, constant voltage charge to stop until 0.02C mA |
| Standard Charge Current | 1C | ||
| Max. Charging Current | 3C | ||
| Discharge Cut-off Voltage | 2.0V | ||
| Standard Discharge Current | 1C | ||
| Max. Continuous Discharge Current | 5C | ||
| Cycle Characteristic | ≥2000 times (100%DOD) ≥4000 times (80%DOD) | The residual capacity is no less than 80% of rated capacity at 1C charge / 5C discharge. | |
| Working Temperature | Charge: 0℃~55℃ Discharge: -20℃~60℃ | ||
| Storage Temperature | -20℃~55℃ | Short-term storage (< 3 months) | |
| Cell Weight | <93g | ||
Characteristics Curves:
Applications:
● Branded Power Banks and Portable Packs
● Custom Packs for Electric Tools and Appliances
● Battery Packs for Light Electric Vehicles
● Medical, Security, and IoT Devices
Ready to Upgrade Your Power?
[➔ Download the Full Specification Sheet (PDF)]
[⮟ Contact Our Experts for a Quote]
| HCITR26/70-36P | |||
| Item | Standard | Note | |
| Standard Capacity | 3600mAh | 1C (current value of 3600mA at 1C) | |
| Minimum Capacity | 3600mAh | ||
| Standard Voltage | 3.2V | ||
| Alternating Internal Resistance | ≤20mΩ | ||
| Charge Conditions | 3.65±0.05V 0.01C | 3.65±0.05V 0.02C | Constant-current charge to 3.65V at 1C, constant voltage charge to stop until 0.02C mA |
| Standard Charge Current | 1C | ||
| Max. Charging Current | 3C | ||
| Discharge Cut-off Voltage | 2.0V | ||
| Standard Discharge Current | 1C | ||
| Max. Continuous Discharge Current | 5C | ||
| Cycle Characteristic | ≥2000 times (100%DOD) ≥4000 times (80%DOD) | The residual capacity is no less than 80% of rated capacity at 1C charge / 5C discharge. | |
| Working Temperature | Charge: 0℃~55℃ Discharge: -20℃~60℃ | ||
| Storage Temperature | -20℃~55℃ | Short-term storage (< 3 months) | |
| Cell Weight | <93g | ||
Our cells incorporate multiple safety features, including proprietary electrode coatings to prevent dendrite formation, built-in CID (Current Interrupt Device) for overpressure protection, and ceramic separators that withstand high temperatures. Each cell undergoes rigorous testing including nail penetration and overcharge tests.
Under standard conditions (25°C, 80% DoD):
LiFePO4 cells: 3,000-5,000 cycles with ≥80% capacity retention
NMC cells: 1,500-2,000 cycles with ≥80% capacity retention
Actual lifespan depends on operating temperature, discharge rates, and maintenance practices.
All cells meet international standards including UN38.3, IEC62619, and UL1642. Our manufacturing process is ISO9001 certified, with complete traceability from raw materials to finished products. Each batch undergoes comprehensive testing including cycle life, internal resistance, and thermal stability assessments.
