Power Your Heavy-Duty Electric Forklifts
Our 48V LiFePO4 battery is engineered for the rigorous demands of modern electric forklifts and large material handling equipment. Delivering consistent high power for lifting heavy loads and rapid travel speeds, it eliminates the limitations of lead-acid batteries. Experience multi-shift operation with rapid charging, reduced maintenance, and a significantly lower total cost of ownership.
Key Features:
High Voltage & Power Output:
Ideal for 3-wheel and 4-wheel electric forklifts with demanding performance needs.
Ultra-Fast Charging:
Achieves a full charge in 2-3 hours, enabling opportunity charging during breaks.
Maintenance-Free Operation:
No watering, acid leaks, or ventilation required. Safer for your workforce.
Intelligent BMS:
Provides comprehensive protection and state-of-charge monitoring for optimal fleet management.
5x Longer Lifespan:
Outlasts lead-acid batteries by years, reducing replacement costs and downtime.
| TECH & SPECS | Model | ||||||
48V 210Ah battery | 48V 280Ah | 48V 420Ah | 48V 460Ah | 48V 560Ah | 48V 628Ah | ||
| Electrical Specifications | Nominal Voltage Nominal Capacity | 48V(51.2 V) 210Ah | 48V(51.2 V) 280Ah | 48V(51.2 V) 420Ah | 48V(51.2 V) 460Ah | 48V(51.2 V) 560Ah | 48V(51.2 V) 628Ah |
| Stored Energy | 10.75 kWh | 14.34 kWh | 21.50 kWh | 23.55 kWh | 28.67 kWh | 32.15 kWh | |
| Cycle Life | 3000times Cycles @100%DOD and 6000times @80% DOD | ||||||
| Discharge Specifications | Continuous Discharge | 210A | 280A | 350A | 280A | 280A | 280A |
Maximum Discharge | 420A(30s) | 420A(30s) | 700A(30s) | 420A(30s) | 420A(30s) | 420A(30s) | |
| Mechanical Specifications | Dimensions (mm) For Reference | 950*375*550mm | 830 x 414 x 627 mm | 970 x 630 x 571.5 mm | 1223 x 353 x 782 mm | 830 x 630 x 627 mm | 1223 x 499 x 784 mm |
Weight lbs.(kg) With Counterweight | 200kg | 560kg | 300kg | 892kg | 420kg | 1290kg | |
| Case Color/material | Steel | ||||||
| IP Rating | IP65 | ||||||
| Temperature Specifications | Charge Temp | -4°F~131°F(-20°C ~ 55°C) | |||||
| Discharge Temp | -4°F~131°F(-20°C ~ 55°C) | ||||||
| Storage Temp(1 month) | -4°F~113°F (-20°C~45°C) | ||||||
| Storage Temp(1 year) | 32°F~95°F ( 0°C ~ 35°C) | ||||||
Benefits
● Life cycles >3500 cycles.
● Fast charge & No “memory” effect.
● Safety and sustainability reducing carbon footprint.
● No hazardous fumes acid spills or watering.
● Eliminate battery changes at each shift.
● Remote troubleshooting & monitoring.
● Reduced costs & Savings on electricity bills.
● Zero daily maintenance and no battery room required.
● The forklift battery has an excellent charging performance and high energy density.
● It will only take a little charging time. Therefore, you can save a lot of time for workers.
● Our lithium forklift battery is easier and more convenient to use and does not require maintenance to ensure its performance.
● The cycle life of the 230 Ah forklift battery is up to 3500 times, contributing to cost savings.
Key Points for Quality Control:
Cell match: More strict cell matching standard, the difference of lnternal resistance is 1mΩ and voltage is 5mV.
Automatic cells welding: Cells are assembled by Automatic welding equipments to ensure the quality reliability and consistency.
100% Cycle test: All battery packs are 100% cycle tested (Fully Discharged→Fully Charged→Fully Discharged→60% Charged) before package and all test reports are stored.
Unique tracking number: All battery packs are lasered an unique number on the case side for quality tracking.
Certifications:
| UL1642(Cell) | IEC62619 (Cell) | UN38.3(Cell/ Pack) |
| IEC62133(Cell) | ROHS(Cell) | CE(Pack) |
Support multiple protection, including battery reverse polarity protection, output short circuit protection, output over/under voltage protection, over-temperature protection, and input over/under voltage protection, for ultimate charging safety.
Key Benefits:
Higher qualified cylindrical cell:
UL1642, IEC62619, IEC62133 listed with Cycle life more than 3000times and excellent consistency.
Bluetooth:
enable to monitor the battery status(charge, discharge, current, temperature, cycle life and so on) and change the data for different applications.
Heating function system:
Uniform internal heating is an important feature of our cold-weather performance batteries, as many external heating blanket options currently available cannot sense the internal temperature of the cells and may not be completely effective at heating the battery throughout. The system features proprietary technology that draws power from the charger itself, requiring no additional components. The entire process of heating and charging is completely seamless. Simply plug the battery into the regular lithium charger and the internal heating and monitoring system takes care of the rest.
More stable and firm internal structure:
Cell holders can well protect and separate the cells to avoid any circuit short risk caused by vibration or impact or over current, and improve the heat dissipation.
Smaller size and less weight:
The size of our battery is just 3/4 size of the standard 12V 100Ah battery from other suppliers.
Idea For:
● Electric Counterbalance Forklifts (3,000 - 5,000 lbs capacity)
● Large Electric Pallet Jacks and Tow Tractors
● Heavy-Duty Material Handling Equipment
Customized items:
Bluetooth App design: Help you to design and upload customized App, or supply you our Source code for your design.
Case color: Customized case color is acceptable based on quantity more than 300pcs per batch.
Label design: We can help you to design customized label on the battery.
Carton design: Customized carton is acceptable based on quantity more than 200pcs per batch.
Certificates: 50% discount on certificates cost for first bulk order and 100% reback for future orders.
NDA agreement: NDA agreement is allowed and necessary to protect your benefits.
Ready to Upgrade Your Power?
[➔ Download the Full Specification Sheet (PDF)]
[⮟ Contact Our Experts for a Quote]
